Smart Mapper (CSV/XLSX Bulk Import)

Smart Mapper lets you upload a spreadsheet, map columns to template fields, and apply the results directly into the editor form. Save recipes for monthly imports and re-run with minimal setup.

Smart Mapper Live Demo

Features

  • Profile CSV/XLSX headers + sample rows with column statistics (null rate, distinct count)
  • Drag-and-drop columns onto targets with a visual mapping canvas
  • Semantic-aware auto-mapping suggests matches using semantic synonyms and field names
  • Map columns → idShortPath targets (including list paths via [])
  • Transformation options per mapping: trim whitespace, decimal/thousands separators, date format
  • Import modes: single, row-per-submodel, and grouped (build list items per group)
  • Save recipes locally or to the server (OIDC-aware scoping)
  • Template version tracking warns when the template has been updated since the recipe was saved
  • Dry-run preview shows mapped values before applying to the form
  • Validation panel flags unmapped required fields and parsing warnings

Workflow

  1. Upload a CSV or XLSX file
  2. Review column profiles (sample values, null rates, distinct counts)
  3. Drag columns onto template fields or use auto-suggest
  4. Configure transformations if needed
  5. Preview mapped values
  6. Apply to form or export directly

Configuration

Recipes can be saved locally (browser storage) or to the server. When OIDC authentication is enabled, server-stored recipes are scoped to the authenticated user.

API Endpoints

  • POST /api/mapper/profile - Profile CSV/XLSX headers + sample rows (includes column statistics)
  • POST /api/mapper/auto-suggest - Auto-suggest column mappings using semantic matching
  • POST /api/mapper/run - Run mapping (form or export output)
  • GET /api/mapper/recipes - List saved recipes (scoped by OIDC user if enabled)
  • POST /api/mapper/recipes - Save recipe to server
  • GET /api/mapper/recipes/{name} - Fetch a recipe
  • DELETE /api/mapper/recipes/{name} - Delete a recipe
